Production Introduction

Bullet Proof Aramid Fabric is crafted from aramid fiber filaments or yarns, and can also include hybrid options such as carbon-aramid or fiberglass-aramid blends. Available weave patterns include unidirectional, plain, twill, interweave, and non-woven types. The fabric is offered in a range of colors, including yellow, yellow/black, army green, navy blue, and red. It boasts features like low density, minimal shrinkage, dimensional stability, high tensile strength, high modulus, and excellent resistance to heat and chemicals. Common applications include aviation, concrete reinforcement, protective gear, bulletproof sheets, sports gear, and vehicle components. Fabric with coatings such as PTFE, PVC, silicone, or aluminum foil is also available.

Technical Parameters

Products	Para Aramid Filament Yarn Fabric
Type	1000D 200gsm
Weaving Style	Plain
Unit weight	200gsm
Width	100CM
Tensile strength of Warp yarn(N/cm)	1560
Tensile strength of Weft yarn(N/cm)	1330
Warp yarn count(Nr/cm)	9.1
Weft yarn count(Nr/cm)	8.7
Oil Pick-up(%)	1.27
Thick-ness(mm)	0.25
For more specifications, please contact customer service. Thank you!
